# Place "config.txt" changes (dtparam, dtoverlay, disable_overscan, etc.) in
# this file. Please refer to the README file for a description of the various
# configuration files on the boot partition.
## Custom Slot is hdmi_grpoup=1 & hdmi_mode=65
### For this define, it uses mode 87, which is 1 above the defined modes...
#### Custom mode define ####
# hdmi_cvt=<width> <height> <framerate> <aspect> <margins> <interlace> <rb>
# width width in pixels
# height height in pixels
# framerate framerate in Hz
# aspect aspect ratio 1=4:3, 2=14:9, 3=16:9, 4=5:4, 5=16:10, 6=15:9
# margins 0=margins disabled, 1=margins enabled
# interlace 0=progressive, 1=interlaced
# rb 0=normal, 1=reduced blanking
###
#hdmi_cvt=1920 1080 60 3 0 0 0 # Custom mode definition
#hdmi_group=2
#hdmi_mode=87 #1 mode above defines in AEC
### Normal Mode Sets
hdmi_group=2 # 0:Autodetect EDID, 1:AEC, 2:DMT
hdmi_mode=82 # 1920x1080 60Hz
### For sound through HDMI ###
#hdmi_drive=2 # hdmi with sound
###########################################################
## If all above is commented, this displays as 1824x984 9:5
###########################################################
### If hdmi_group=1 AEC, then these
###########################################################
## Set to 640x480 60hz 4:3 VGA
#hdmi_mode=1
## Set to 480p 60hz 4:3
#hdmi_mode=2
## Set to 480p 60hz 16:9
#hdmi_mode=3
## Set to 720p 60hz 16:9
#hdmi_mode=4
## Set to 1080i 60hz 16:9
#hdmi_mode=5
## Set to 480i 60hz 4:3
#hdmi_mode=6
## Set to 480i 60hz 16:9
#hdmi_mode=7
## Set to 240p 60hz 4:3
#hdmi_mode=8
## Set to 240p 60hz 16:9
#hdmi_mode=9
## Set to 480i 60hz 4:3
#hdmi_mode=10
## Set to 480i 60hz 16:9
#hdmi_mode=11
## Set to 240p 60hz 4:3
#hdmi_mode=12
## Set to 240p 60hz 16:9
#hdmi_mode=13
## Set to 480p 60hz 4:3
#hdmi_mode=14
## Set to 480p 60hz 16:9
#hdmi_mode=15
## Set to 480p 60Hz 16:9
#hdmi_mode=16
## Set to 576p 50Hz 4:3
#hdmi_mode=17
## Set to 576p 50Hz 16:9
#hdmi_mode=18
## Set to 720p 50hz 16:9
#hdmi_mode=19
## Set to 1080i 50hz 16:9
#hdmi_mode=20
## Set to 576i 50hz 4:3
#hdmi_mode=21
## Set to 576i 50hz 16:9
#hdmi_mode=22
## Set to 288p 50 hz 4:3
#hdmi_mode=23
## Set to 288p 50hz 16:9
#hdmi_mode=24
## Set to 576i 50hz 4:3
#hdmi_mode=25
## Set to 576i 50hz 16:9
#hdmi_mode=26
## Set to 288p 50Hz 4:3
#hdmi_mode=27
## Set to 288p 50Hz 16:9
#hdmi_mode=28
## Set to 576p 50Hz 4:3
#hdmi_mode=29
## Set to 576p 50Hz 16:9
#hdmi_mode=30
## Set to 1080p 50Hz 16:9
#hdmi_mode=31
## Set to 1080p 24Hz 16:9
#hdmi_mode=32
## Set to 1080p 25Hz 16:9
#hdmi_mode=33
## Set to 1080p 30Hz 16:9
#hdmi_mode=34
## Set to 480p 60Hz 4:3
#hdmi_mode=35
## Set to 480p 60Hz 16:9
#hdmi_mode=36
## Set to 576p 50Hz 4:3
#hdmi_mode=37
## Set to 576p 50Hz 16:9
#hdmi_mode=38
## Set to 1080i 50Hz 16:9
#hdmi_mode=39
## Set to 1080i 100Hz 16:9
#hdmi_mode=40
## Set to 720p 100Hz 16:9
#hdmi_mode=41
## Set to 576p 100Hz 4:3
#hdmi_mode=42
## Set to 576p 100Hz 16:9
#hdmi_mode=43
## Set to 576i 100Hz 4:3
#hdmi_mode=44
## Set to 576i 100hz 16:9
#hdmi_mode=45
## Set to 1080i 120Hz 16:9
#hdmi_mode=46
## Set to 720p 120Hz 16:9
#hdmi_mode=47
## Set to 480p 120Hz 4:3
#hdmi_mode=48
## Set to 480p 120Hz 16:9
#hdmi_mode=49
## Set to 480i 120Hz 4:3
#hdmi_mode=50
## Set to 480i 120Hz 16:9
#hdmi_mode=51
## Set to 576p 200Hz 4:3
#hdmi_mode=52
## Set to 576p 200Hz 16:9
#hdmi_mode=53
## Set to 576i 200Hz 4:3
#hdmi_mode=54
## Set to 576i 200Hz 16:9
#hdmi_mode=55
## Set to 480p 240Hz 4:3
#hdmi_mode=56
## Set to 480p 240Hz 16:9
#hdmi_mode=57
## Set to 480i 240Hz 4:3
#hdmi_mode=58
## Set to 480i 240Hz 16:9
#hdmi_mode=59
## Set to 720p 24Hz 16:9
#hdmi_mode=60
## Set to 720p 25Hz 16:9
#hdmi_mode=61
## Set to 720p 30Hz 16:9
#hdmi_mode=62
## Set to 1080p 120Hz 16:9
#hdmi_mode=63
## Set to 1080p 100Hz 16:9
#hdmi_mode=64
## Set to Custom
#hdmi_mode=65
## Set to 720p 25Hz 64:27 Pi 4
#hdmi_mode=66
## Set to 720p 30Hz 64:27 Pi 4
#hdmi_mode=67
## Set to 720p 50Hz 64:27 Pi 4
#hdmi_mode=68
## Set to 720p 60Hz 64:27 Pi 4
#hdmi_mode=69
## Set to 720p 100Hz 64:27 Pi 4
#hdmi_mode=70
## Set to 720p 120Hz 64:27 Pi 4
#hdmi_mode=71
## Set to 1080p 24Hz 64:27 Pi 4
#hdmi_mode=72
## Set to 1080p 25Hz 64:27 Pi 4
#hdmi_mode=73
## Set to 1080p 30Hz 64:27 Pi 4
#hdmi_mode=74
## Set to 1080p 50Hz 64:27 Pi 4
#hdmi_mode=75
## Set to 1080p 60Hz 64:27 Pi 4
#hdmi_mode=76
## Set to 1080p 100Hz 64:27 Pi 4
#hdmi_mode=77
## Set to 1080p 120Hz 64:27 Pi 4
#hdmi_mode=78
## Set to 1680x720 24Hz 64:27 Pi 4
#hdmi_mode=79
## Set to 1680x720 25z 64:27 Pi 4
#hdmi_mode=80
## Set to 1680x720 30Hz 64:27 Pi 4
#hdmi_mode=81
## Set to 1680x720 50Hz 64:27 Pi 4
#hdmi_mode=82
## Set to 1680x720 60Hz 64:27 Pi 4
#hdmi_mode=83
## Set to 1680x720 100Hz 64:27 Pi 4
#hdmi_mode=84
## Set to 1680x720 120Hz 64:27 Pi 4
#hdmi_mode=85
## Set to 2560x720 24Hz 64:27 Pi 4
#hdmi_mode=86
## Set to 2560x720 25Hz 64:27 Pi 4
#hdmi_mode=87
## Set to 2560x720 30Hz 64:27 Pi 4
#hdmi_mode=88
## Set to 2560x720 50Hz 64:27 Pi 4
#hdmi_mode=89
## Set to 2560x720 60Hz 64:27 Pi 4
#hdmi_mode=90
## Set to 2560x720 100Hz 64:27 Pi 4
#hdmi_mode=91
## Set to 2560x720 120Hz 64:27 Pi 4
#hdmi_mode=92
## Set to 2160p 24Hz 16:9 Pi 4
#hdmi_mode=93
## Set to 2160p 25Hz 16:9 Pi 4
#hdmi_mode=94
## Set to 2160p 30Hz 16:9 Pi 4
#hdmi_mode=95
## Set to 2160p 50Hz 16:9 Pi 4
#hdmi_mode=96
## Set to 2160p 60Hz 16:9 Pi 4
#hdmi_mode=97
## Set to 4096x2160 24Hz 256:135 Pi 4
#hdmi_mode=98
## Set to 4096x2160 25Hz 256:135 Pi 4
#hdmi_mode=99
## Set to 4096x2160 30Hz 256:135 Pi 4
#hdmi_mode=100
## Set to 4096x2160 50Hz 256:135 Pi 4
#hdmi_mode=101
## Set to 4096x2160 60Hz 256:135 Pi 4
#hdmi_mode=102
## Set to 2160p 24Hz 64:27 Pi 4
#hdmi_mode=103
## Set to 2160p 25Hz 64:27 Pi 4
#hdmi_mode=104
## Set to 2160p 30Hz 64:27 Pi 4
#hdmi_mode=105
## Set to 2160p 50Hz 64:27 Pi 4
#hdmi_mode=106
## Set to 2160p 60Hz 64:27 Pi 4
#hdmi_mode=107
############################################
### If hdmi_group=2, then thse are valid ###
############################################
## Set to 640x350 85Hz
#hdmi_mode=1
## Set to 640x400 85Hz 16:10
#hdmi_mode=2
## Set to 720x400 85Hz
#hdmi_mode=3
## Set to 640x480 60Hz 4:3
#hdmi_mode=4
## Set to 640x480 72Hz 4:3
#hdmi_mode=5
## Set to 640x480 75Hz 4:3
#hdmi_mode=6
## Set to 640x480 85Hz 4:3
#hdmi_mode=7
## Set to 800x600 56Hz 4:3
#hdmi_mode=8
## Set to 800x600 60Hz 4:3
#hdmi_mode=9
## Set to 800x600 72Hz 4:3
#hdmi_mode=10
## Set to 800x600 75Hz 4:3
#hdmi_mode=11
## Set to 800x600 85Hz 4:3
#hdmi_mode=12
## Set to 800x600 120Hz 4:3
#hdmi_mode=13
## Set to 848x480 60Hz 16:9
#hdmi_mode=14
## Set to 1024x768 43Hz 4:3 incompatible with the Raspberry Pi
#hdmi_mode=15
## Set to 1024x768 60Hz 4:3
#hdmi_mode=16
## Set to 1024x768 70Hz 4:3
#hdmi_mode=17
## Set to 1024x768 75Hz 4:3
#hdmi_mode=18
## Set to 1024x768 85Hz 4:3
#hdmi_mode=19
## Set to 1024x768 120Hz 4:3
#hdmi_mode=20
## Set to 1152x864 75Hz 4:3
#hdmi_mode=21
## Set to 1280x768 60Hz 15:9 reduced blanking
#hdmi_mode=22
## Set to 1280x768 60Hz 15:9
#hdmi_mode=23
## Set to 1280x768 75Hz 15:9
#hdmi_mode=24
## Set to 1280x768 85Hz 15:9
#hdmi_mode=25
## Set to 1280x768 120Hz 15:9 reduced blanking
#hdmi_mode=26
## Set to 1280x800 60 16:10 reduced blanking
#hdmi_mode=27
## Set to 1280x800 60Hz 16:10
#hdmi_mode=28
## Set to 1280x800 75Hz 16:10
#hdmi_mode=29
## Set to 1280x800 85Hz 16:10
#hdmi_mode=30
## Set to 1280x800 120Hz 16:10 reduced blanking
#hdmi_mode=31
## Set to 1280x960 60Hz 4:3
#hdmi_mode=32
## Set to 1280x960 85Hz 4:3
#hdmi_mode=33
## Set to 1280x960 120Hz 4:3 reduced blanking
#hdmi_mode=34
## Set to 1280x1024 60Hz 5:4
#hdmi_mode=35
## Set to 1280x1024 75Hz 5:4
#hdmi_mode=36
## Set to 1280x1024 85Hz 5:4
#hdmi_mode=37
## Set to 1280x1024 120Hz 5:4 reduced blanking
#hdmi_mode=38
## Set to 1360x768 60Hz 16:9
#hdmi_mode=39
## Set to 1360x768 120Hz 16:9 reduced blanking
#hdmi_mode=40
## Set to 1400x1050 60Hz 4:3 reduced blanking
#hdmi_mode=41
## Set to 1400x1050 60Hz 4:3
#hdmi_mode=42
## Set to 1400x1050 75Hz 4:3
#hdmi_mode=43
## Set to 1400x1050 85Hz 4:3
#hdmi_mode=44
## Set to 1400x1050 120Hz 4:3 reduced blanking
#hdmi_mode=45
## Set to 1440x900 60Hz 16:10 reduced blanking
#hdmi_mode=46
## Set to 1440x900 60Hz 16:10
#hdmi_mode=47
## Set to 1440x900 75Hz 16:10
#hdmi_mode=48
## Set to 1440x900 85Hz 16:10
#hdmi_mode=49
## Set to 1440x900 120Hz 16:10 reduced blanking
#hdmi_mode=50
## Set to 1600x1200 60Hz 4:3
#hdmi_mode=51
## Set to 1600x1200 65Hz 4:3
#hdmi_mode=52
## Set to 1600x1200 70Hz 4:3
#hdmi_mode=53
## Set to 1600x1200 75Hz 4:3
#hdmi_mode=54
## Set to 1600x1200 85Hz 4:3
#hdmi_mode=55
## Set to 1600x1200 120Hz 4:3 reduced blanking
#hdmi_mode=56
## Set to 1680x1050 60Hz 16:10 reduced blanking
#hdmi_mode=57
## Set to 1680x1050 60Hz 16:10
#hdmi_mode=58
## Set to 1680x1050 75Hz 16:10
#hdmi_mode=59
## Set to 1680x1050 85Hz 16:10
#hdmi_mode=60
## Set to 1680x1050 120Hz 16:10 reduced blanking
#hdmi_mode=61
## Set to 1792x1344 60Hz 4:3
#hdmi_mode=62
## Set to 1792x1344 75Hz 4:3
#hdmi_mode=63
## Set to 1792x1344 120Hz 4:3 reduced blanking
#hdmi_mode=64
## Set to 1856x1392 60Hz 4:3
#hdmi_mode=65
## Set to 1856x1392 75Hz 4:3
#hdmi_mode=66
## Set to 1856x1392 120Hz 4:3 reduced blanking
#hdmi_mode=67
## Set to 1920x1200 60Hz 16:10 reduced blanking
#hdmi_mode=68
## Set to 1920x1200 60Hz 16:10
#hdmi_mode=69
## Set to 1920x1200 75Hz 16:10
#hdmi_mode=70
## Set to 1920x1200 85Hz 16:10
#hdmi_mode=71
## Set to 1920x1200 120Hz 16:10 reduced blanking
#hdmi_mode=72
## Set to 1920x1440 60Hz 4:3
#hdmi_mode=73
## Set to 1920x1440 75Hz 4:3
#hdmi_mode=74
## Set to 1920x1440 120Hz 4:3 reduced blanking
#hdmi_mode=75
## Set to 2560x1600 60Hz 16:10 reduced blanking
#hdmi_mode=76
## Set to 2560x1600 60Hz 16:10
#hdmi_mode=77
## Set to 2560x1600 75Hz 16:10
#hdmi_mode=78
## Set to 2560x1600 85Hz 16:10
#hdmi_mode=79
## Set to 2560x1600 120Hz 16:10 reduced blanking
#hdmi_mode=80
## Set to 1366x768 60Hz 16:9 NOT on Pi4
#hdmi_mode=81
## Set to 1920x1080 60Hz 16:9 1080p
#hdmi_mode=82
## Set to 1600x900 60Hz 16:9 reduced blanking
#hdmi_mode=83
## Set to 2048x1152 60Hz 16:9 reduced blanking
#hdmi_mode=84
## Set to 1280x720 60Hz 16:9 720p
#hdmi_mode=85
## Set to 1366x768 60Hz 16:9 reduced blanking
#hdmi_mode=86
#############################################################
## HDMI Safe Mode
#hdmi_safe=1
